The transition to electric vehicles (EVs) is highly dependent on the development of a robust charging infrastructure. A battery – which is what powers these cars – is only useful if there is a system in place that can charge it. The notion of charging an EV comes with much more than just plugging in a vehicle; it considers complicated technology, different levels of power, and fast-evolving public infrastructure. To fully understand the adoption of electric mobility, users need to be aware of the complexities of EV charging, since these will dictate convenience, cost, and the lifespan of a vehicle. This article will look at the different levels of power, conflicting global standards for EV charging, and future considerations for power that will change the EV charging experience.
The Three Levels of EV Charging
There are three distinct levels of electric vehicle charging that each differ in their power source and charging speeds.
Level 1 Charging: This is the most basic option in electric vehicle charging. It connects into a common 120-volt (V) AC outlet typically available in residential settings, generally not requiring anything else besides the EV’s charging cord. Level 1 charging is the most inefficient method of charging, typically gaining only 3 to 7 miles of range for each hour of charging. Despite being convenient as an overnight charge from home when you have a plugin hybrid electric vehicle (PHEV) or electric vehicle (EV) with a smaller battery, it is often too slow for a full battery electric vehicle (BEV) to charge from empty to full overnight. It is often considered a reliable backup for EV charging.
Level 2 Charging: This is the most common and flexible kind of EV charging, used most often in homes, workplaces, and other community sites. Level 2 chargers generally use 208V or 240V AC power, deriving electrical flow from the same general circuits that dryers and ovens use, and they require specialized equipment (Electric Vehicle Supply Equipment, EVSE). Charging using Level 2 is a substantial improvement over Level 1 charging speed, delivering between 12 and 80 miles of range in an hour, depending on the specific vehicle, or nearly fully charging most BEVs in roughly 4-10 hours based on battery size. Level 2 chargers balance speed and accessibility and become the fundamental method of charging. A professionally installed home wall box is a defined level 2 EV charging station.
Level 3 (DC Fast Charging or DCFC): This is the fastest way to charge an EV because it bypasses the EV’s in-vehicle AC-to-DC converter and delivers high-powered direct current (DC) into the battery. Level 3 electric vehicle chargers are found, generally, around highways or key public locations. Level 3 chargers will deliver anywhere from 50 kW to 350 kW and higher. It will allow an average EV to charge up to 80% state-of-charge in 20 to 40 minutes, depending on the charge acceptance rate of the vehicle, and the performance of the charger. DC Fast Charging is essential for traveling long distances and for urgent EV charging needs.
Standards and Connectors: The Plug Wars
A major complexity in the global EV charging infrastructure is the existence of competing connector and communication standards. Electric vehicle (EV) charging standards, which define both the physical plug shape and the digital language the vehicle and charge station communicate power requirements and safety protocols, include:
Combined Charging System (CCS): This standard uses a single port on the vehicle for both Level 2 AC and Level 3 DC charging. It is the most common standard in the United States (CCS1) and Europe (CCS2) and has been adopted by major automakers in the U.S. and Europe. CCS is capable of charging EVs up to 500 kW, providing a loading mechanism for the most demanding power reeds for EV charging.
CHAdeMO: Originating in Japan, this direct current-only standard features a distinct, larger connector. Although it was once prevalent, its global market share is decreasing, yet numerous older Japanese EVs continue to depend on it for DC EV charging.
North American Charging Standard (NACS): Initially created by Tesla for its Supercharger network, NACS features a streamlined, compact design that accommodates both AC and DC EV charging using a single plug. Thanks to its intuitive design and Tesla’s extensive network, numerous leading automakers have revealed intentions to incorporate the NACS port in their upcoming models, which could establish it as the common standard for EV charging in North America. The shift towards NACS will make the public EV charging experience easier.
Impact of Fast Charging and Battery Health
A common concern among EV owners is the effect of frequent DC fast EV charging on battery longevity. It is true that the high currents and voltage used in Level 3 charging generate more heat than Level 1 or Level 2 charging. Excessive heat is the primary factor that accelerates battery degradation over time.
Current electric vehicles and charging systems have modern thermal management and Battery Management Systems (BMS) to mitigate this risk. The charger and vehicle are in constant “communication” with the power supply, explaining why charging speeds are reduced when the battery reaches about 80%. Typically, manufacturers recommend using Level 3 EV charging for special occasions, such as long driving trips, while using Level 2 for the daily EV charging needs to support battery health. In general, the infrequent use of fast EV charging is thought to have negligible effects in the longer-term, however, repeated fast EV charging over years may result in a slight reduction in maximum capacity.
Future of EV Charging: Innovation and Grid Integration
The future of EV charging will be determined by smart integration and innovative solutions. An important challenge for the infrastructure will be the potential stress on the local electricity grid at the moment of multiple EVs plugging the same time as peak demand hours.
Smart Charging and V2G: Smart charging is a growing tool in which utilities and charging networks can reduce demand by adjusting charging speed in relation to grid load and electricity price.A major technological leap will be Vehicle-to-Grid (V2G) technology, which allows EVs to send stored energy back to the grid during peak demand times. This transforms the EV from a passive consumer into a mobile energy asset, revolutionizing the entire concept of EV charging and grid stability.
Wireless Charging: Wireless, or inductive, EV charging is still being developed. In this method of charging, magnetic fields are used to transfer power from an underground coil embedded in the pavement to a coil located on the bottom of the vehicle (no cables). Although it is still less efficient than a plug in an EV charger, this method can be implemented for stationary (such as public parking lots) and dynamic (charging while driving) applications with unmatched convenience.
In summary, EV charging infrastructure is a dynamic space that is evolving rapidly. There are numerous solutions to meet all of our charging needs, from the simplicity of Level 1 home charging to the need for Level 3 highway charging. As standards begin to stabilize and V2G and vehicle-grid technology integrates into standard utility practices, the experience of charging EVs will be faster, smarter, and as seamless and compatible with our lifestyles as the energy grid itself. R&D and investment into EV charging infrastructure are critical to achieving large-scale spent electric mobility.
